Yaesu FT-8900R

YAESU FT-8900R

Rig Yaesu FT-8900R

Feature :

Convenient Remote-Head Mounting Capability

Having trouble mounting your mobile radio in your compact car? With the FT-8900R and its optional YSK-8900 Separation Kit, mounting is a breeze even in the tightest locations. The YSK-8900 includes a 20’ (6 m) remote cable and a mounting bracket for the front panel, and the microphone jack is located on the side of the front panel, eliminating the need to run a separate cable.

Convenient Access to WIRES and other Internet-linking Systems

When six and ten meters are dead, you can still talk around the world with the FT-8900R! The front panel provides easy access to any WIRES™ (Wide-coverage Internet Repeater Enhancement System) repeater, automatically sending the required single DTMF access code at the beginning of each transmission. And if you’re using another Internet linking system, one that requires a DTMF string to being up the link, you can easily configure the FT-8900R to store and send the required tone sequence, as well!

Quad Band Operation

The FT-8900R combines the “traditional” 144/430 MHz local-communications concept with the exciting capability for Sporadic-E or F2 DX on the 29 MHz and 50 MHz bands, for nationwide or worldwide FM communications from your car! The first Amateur Radio FM mobile transceiver providing this capability, the FT-8900R will make you wonder how you got by with a two-band transceiver up to now!

Wide Frequency Coverage

The FT-8900R provides extended receiver coverage beyond the Amateur bands, so you can keep informed of communication activities in the public safety, commercial, aircraft, and government communications ranges. Included is coverage of 28-29.7 MHz, 50-54 MHz, 108-180 MHz, 300-480 MHz, and 700-985 MHz (cellular frequencies are blocked and non-restorable).

High Power Output

To get your message through when it counts, the FT-8900R puts out a full 50 Watts of power on the 29/50/144 MHz bands, and 35 Watts on 430 MHz. To ensure thermal stability during long transmissions, a thermal sensor monitors heat sink temperature, engaging the rear panel’s cooling fan only when needed.

Over 800 Memory Channels

The FT-8900R provides a wide variety of memory resources, including 799 “regular” memories, six “Home” channels for favorite frequencies, five sets of band-edge memories, and six “Hyper Memory” memories, which store complete transceiver operating status, for maximum operating efficiency and convenience. Six-character Alpha-Numeric “Tags” (labels) may be appended to memory channels, affording instant channel identification. No transceiver can compare with the memory capability of the FT-8900R!

Cross-Band Repeat Capability

For emergency work, or to extend the range of a hand-held unit, the FT-8900R includes Cross-Band Repeat capability, similar to that pioneered on our popular FT-8100R Dual Band FM Mobile!

One-Touch Band-Pattern

To save valuable time while operating a transceiver with the versatility of the FT-8900R, the “Hyper Memory” feature allows you to store a complete set of configuration data for the two bands on which you’re operating. Besides the usual storage of frequency and tone data, Hyper Memory will store such setup parameters as Automatic Repeater Shift status, Packet parameters, Scanning mode, and VFO tracking, avoiding the need to change each of these functions manually on a regular basis.

CTCSS and DCS Encoders Built In

Providing excellent performance even under difficult link conditions, Yaesu’s 50-tone sub-audible CTCSS and 104-tone DCS signaling systems ensure that you have full access to repeater and remote-base inputs, and the built-in CTCSS/DCS decoders allow silent listening on busy channels. Plus you get Tone Search Scanning, which will scan for the tone being received on an incoming signal, allowing you to match tones quickly when operating on a new repeater system

Easy Setup for FM Satellite Operation

For operating on FM satellites like UO-14, the versatile memory system of the FT-8900R allows you to store a set of uplink and downlink frequencies that account for Doppler shift over the entire horizon-to-horizon pass, allowing you to select the optimum uplink/downlink combination effortlessly!

Truly Independent Two-Channel Operation

Basically operating as two radios in one, the FT-8900R may be configured in a number of ways. For example, you can set up the “left” side of the rig for operation on 29, 50, 144, or 430 MHz operation, while setting the “right” side either to 144 MHz or 430 MHz. And, if you like, you can configure the FT-8900R for 144-144 MHz or 430-430 MHz Dual Receive operation, so you’ll never miss out on the action!

The left and right sides have their own Volume and Squelch controls, as well as S-Meters, so your operating preferences are never compromised.

YAESU FT-8900R is a ruggedly-built, high quality Quad Band FM transceiver providing 50 Watts of power output on the 29/50/144 MHz Amateur bands

Specifications :

GENERAL
Frequency Range Receive:	28-29.7, 50-54, 108-180, 320-480 and 700-985 MHz (cellular blocked).
Frequency Range Transmit:	28-29.7, 50-54, 144-148, 430-450 MHz
Frequency Steps:	5/10/12.5/15/20/25/50 kHz
Operating Modes:	F3, F2, F1
Antenna Impedance:	50 Ohm, Unbalanced
Antenna Jack:	SO-239 [U.S.A. version]
Frequency Stability:	±5 ppm -4°F to 140°F (-20°C to +60°C)
Supply Voltage:	DC 13.8V ±15%, Negative Ground
Current Consumption:	Receive Squelched – Less than 0.5 A
	TX	HI
	50/430 MHz	8.0 A
	430 MHz	8.5 A
Operating Temperature Range:	-20°C to +60°C (-4°F to +140°F)
Case Size:	5.5×1.6×6.6 inches (140x42x168 mm)
Weight:	Approx. 2.2 lbs. (1.0 kg)
TRANSMITTER
RF Power Output:	50/20/10/5 Watts (29/50/144 MHz)
	35/20/10/5 Watts (430 MHz)
Modulation Type:	Variable Reactance
Maximum Deviation:	±5 kHz
Spurious Radiation:	-60 dB or better
Microphone Impedance:	2 K Ohm
Data Jack Impedance:	10 K Ohm
RECEIVER
Circuit Type:	Double-Conversion Superheterodyne
Intermediate Frequencies:	45.05 MHz & 450 kHz (Left band)
	47.25 MHz & 450 kHz (Right band)
Sensitivity (12dB SINAD):	<0.2uV
Selectivity:	12 kHz/30 kHz (-6/-60 dB)
Squelch Sensitivity:	Better than 0.16uV
AF Output:	2W @ 8 Ohm @ 5% THD
AF Output Impedance:	4-16 Ohm (Internal Speaker 8 Ohm)
	Specifications are subject to change.
