• Baru
FT-857D
FT-857D
FT-857D

Yaesu FT-857D

Ready Stock
Rp13.600.000
Excl. PPN 10%

Yaesu FT-857D, radio SSB/mobil HF/VHF/UHF terkecil di dunia, merupakan tipe radio base yang ultra-kompak dan ideal untuk pekerjaan eksternal dan mobile. Cakupan frekuensi yang luas, band 160 hingga 6 meter plus 144 MHz dan 430 MHz, kinerja penerima yang luar biasa, dan kenyamanan operasi menjadikan FT-857D pilihan terbaik!

Radio ini dilengkapi dengan sirkuit DSP.

FEATURES YAESU FT-857D

Ultra Compact Design Measuring just 6.1” x 2” x 9.2”, the FT-857 is the world’s smallest HF/VHF/UHF up to 100W multimode transceiver! Its rugged case design is a masterpiece of ergonomic design, with often-used switches and knobs conveniently positioned for easy access.

High-Performance Receiver Design

Building on the acclaimed performance of the FT-1000D, Mark-V FT-1000MP, and FT-897, Yaesu’s engineers have crafted the FT-857’s front end for a very low noise floor, along with wide dynamic range. Utilizing an up-conversion architecture for HF with a first IF of 68.33 MHz, the FT-857 features a double-conversion superheterodyne system (triple conversion on FM), with the 2nd IF at 10.7 MHz. Extensive bandpass filtering in the front end, along with careful device selection and gain distribution, yield a receiver system ready for the strong-signal challenges of today’s crowded bands!

Wide Frequency Coverage

Providing transmitter coverage of the HF, 50 MHz, 144 MHz, and 430 MHz Amateur bands, the FT-857 also includes receive coverage on 100 kHz to 56 MHz, 76 to 108 MHz, 118-164 MHz, and 420-470 MHz. Enjoy the excitement of public safety monitoring, along with weather broadcasts, AM and FM broadcasts, aviation communications, as well as the action on the Ham bands!

Versatile Memory System

The FT-857 provides up to 200 “Main” memory channels, each of which may be named with an Alpha-Numeric label of up to eight characters. These 200 Memories may be separated into as many as 10 Memory Groups of 20 Memories each. For added convenience, you also get a “Quick Memory” and a “Home Channel” on each band, plus ten pairs of band-limit memories, to let you restrict operation to a sub-band, if you like.

Digital Signal Processing (option)

For superior interference rejection and transmitter “talk power,” the FT-857’s optional DSP circuitry enhances both sides of the communications circuit. The FT-857’s DSP Unit features a 24-bit high-tech D/A chip for signal processing. Included are Bandpass Filter, Auto-Notch, and Noise Reduction filters, along with a Microphone Equalizer.

Big Radio Tuning Dial and Outstanding Ergonomics

Ease of operation of the FT-857 is enhanced by the large-diameter (1.7”) Main Tuning Dial, similar in size to the tuning knob of many base station rigs. Selectable tuning steps of 2 kHz/4 kHz per revolution allow easy navigation around your favorite bands, while important keys and switches are strategically placed around the front panel for quick access.

SPECIFICATIONS YAESU FT-857D

GENERAL
Frequency Range: Receive:
0.1-56, 76-108, 118-164 and 420-470 MHz
Transmit:
160 - 6 Meters including 60 Meters
2 Meters
70 Centimeters (Amateur bands only)
5167.5 kHz: Alaska Emergency Frequency
(U.S.A. version only)
Emission Modes:
A1 (CW), A3 (AM), A3J (LSB/USB),
F1 (9600 bps Packet), F2 (1200 bps Packet), F3 (FM)
Synthesizer Steps (Min.):
10 Hz (CW/SSB), 100 Hz (AM),
100 Hz (FM), 100 Hz (WFM)
Antenna Impedance:
50 Ohm, Unbalanced
Operating Temp. Range:
-10 °C to +60 °C (14 F to 140 F)
Frequency Stability:
Better than ą4 ppm (-10 °C to +50 °C)
Power Requirements:
DC 13.8V ą10 %, Negative Ground
Current Consumption:
Receive (Squelched): 0.55A,
Receive (Max. Audio): 1A
Transmit: 22A (@ 100W RF output)
Case Size:
6.1" (W) x 2.0" (H) x 9.2" (D) (155 x 52 x 233 mm)
Weight:
4.6 lb. (2.1 kg.)
TRANSMITTER
Power Output:
160 - 6m: 100 Watts (25 Watts AM carrier)
2m: 50 Watts (12.5 Watts AM carrier)
70cm: 20 Watts (5 Watts AM carrier)
Modulation Types: SSB:
Balanced Modulator
FM:
Variable Reactance
AM:
Early Stage (Low Level)
FM Maximum Deviation:
ą5 kHz (ą2.5 kHz on FM-N)
Spurious Radiation: Harmonics:
At least 50 dB down (1.8 - 29.7 MHz)
At least 60 dB down (50/144/430 MHz)
0
Non-harmonic:
At least 50 dB down (1.8 - 29.7 MHz)
At least 60 dB down (50/144/430 MHz)
Carrier Suppression:
At least 40 dB
Opp. Sideband Suppression:
At least 50 dB
SSB Frequency Response:
400 Hz - 2600 Hz (-6 dB)
Microphone Impedance:
200 - 10 k Ohm (Supplied microphone: 2 k Ohm)

RECEIVER
Sensitivity:
SSB/CW AM-N FM
100 kHz - 1.8 MHz (IPO off):
- uV 32 uV -
1.8 - 28 MHz:
0.25 uV 2 uV -
28 - 30 MHz:
0.2 uV 2 uV 0.50 uV
50 - 54 MHz:
0.125 uV 1 uV 0.2 uV
144/430 MHz:
0.125 uV - 0.2 uV
SSB/CW/AM-N figures are for 10 dB S/N, 12 dB SINAD on FM

Squelch Sensitivity: SSB/CW/AM FM
1.8 - 28 MHz: 2.5 uV -
28 - 30 MHz: 2.5 uV 0.32 uV
50 - 54 MHz: 1 uV 0.16 uV
144/430 MHz: 0.5 uV 0.16 uV

Intermediate Frequencies: 0
1st IF: 68.33 MHz (SSB/CW/FM/AM)
10.7 MHz (W-FM)
2nd IF: 455 kHz
Image Rejection: Better than 70 dB (1.8 - 30 MHz, 50 - 54 MHz)
00 Better than 60 dB (144 - 148 MHz, 430 - 450 MHz)
IF Rejection: Better than 60 dB
Selectivity (-6 / -60 dB): 0
SSB/CW: 2.2 kHz/4.5 kHz
CW: 500 Hz/2.0 kHz (Optional YF-122C installed)
CW-N : 300 Hz/1.0 kHz (OptionalYF-122CN installed)
AM: 6 kHz/20 kHz
FM: 15 kHz /30 kHz (-6 / -50 dB)
Audio Output: 2.5 W into 4 Ohm @ 10% THD
Audio Output Impedance: 4 Ohm - 16 Ohm
Specifications are subject to change without notice, and are guaranteed within amateur bands only.
